Description

Cummins Onan 5500-Watt Propane Generator

The Cummins Onan RV QG 5500 LP model 5.5HGJAB-1270 is propane-powered and rated at 5,500 W, 120 V single phase, and 60 Hz.

For Class A, Class B, and Class C RV Motorhomes, truck campers and RV trailer applications, the Cummins Onan RV QG 5500 LP 5.5HGJAB-1270 starts and runs two 15,000 BTU air conditioners with 1000-watts of additional power for lights and other appliances.

Cummins Onan 5500 LP Generator

Cummins incorporates a digital voltage regulator, frequency regulation, and two single-pole 30-Amp Circuit Breakers. The 5500-Watt propane generator comes with 120-inch-long generator output leads for connection to the RV main AC panel and a sealed generator remote start connector. The Cummins Onan RV QG 5500 LP weighs just 288 pounds and has a compact design of 33.6 inches x 22.2 inches x 16.7-inches high.

Go RVing in our national parks without worry. The Onan 5500 LP Generator meets National Park Service sound level requirements of 60 dB(A) or less at 50 feet. The manufacturer rates sound at 69 dB(A) at 10 feet, measured at half load. Vibration isolation makes the Cummins Onan 5500 Propane Generator operation exceptionally smooth and quiet within the full housing. The spark-arresting muffler, enclosed within the integrated housing and steel base, is USDA Forest Service approved.

Cummins Onan 5500 Propane Generator

Microprocessor control with diagnostics and troubleshooting features protection for overcrank and field overload, over/under frequency and loss of AC signal, mechanical faults, and starter faults. The 5500-Watt Propane Generator set operates efficiently and includes a replaceable air cleaner, has automatic choke, and an electric solenoid positive LPG fuel shutoff. Remote rocker-switch starting from the remote panel with 12-volt 3-wire negative ground.

The RV QG 5500 LP comes with a 3-year limited warranty which includes a free 90-day minor adjustment policy plus a lifetime drive warranty.

Package Includes the Cummins Onan 5500 Generator Manual.

Product Specifications

Model

Model Number; 5.5HGJAB-1270

Manufacturer; Onan RV

Made In USA; Yes

Rated Watts; 5.5kW

Rated Amps; 45.8

Voltage; 120V Single Phase

A/C Ton Rating; Dual Roof AC

Decibel Rating; 69 dB(A) @ 10 ft (half load)

Type; Recreational Vehicle Generator

Series Name; Quiet Gas 5500 Series

Features

Starting System; Electric Start

Low Oil Alert; Yes

Hour Meter; No

Weight; 288 lbs

Dimensions; 33.6L x 22.2W x 16.7H

Warranty Information

Consumer Warranty; 3 Year Limited

Engine

Engine Brand; Cummins Onan OHV EH65V

Engine Size; 4-cycle OHV V-Twin

Engine RPM; 2400

Cooling System; Air Cooled

Alternator

Alternator Type; Brushed

Frequency; 60 Hz

Auto Voltage Regulation; Yes

Fuel

Fuel Type; Propane (LP)

Fuel Gauge; No

LP Consumption @ Full Load; 1.1gal/hr

LP Consumption @ Half Load; 0.8 gal/hr

LP Consumption @ No Load; 0.4 gal/hr

To compare output with your RV’s running and starting loads, see our generator sizing guide and generator comparison guide. Confirm the unit’s installation space and RV compatibility before purchase.
