Description
Upgrade the front brakes with the Wilwood Forged Narrow Superlite 6R Big Brake Front Brake Kit, part number 140-8922-R. This application-specific kit pairs forged billet aluminum six-piston calipers with large vented, slotted rotors. Wilwood states the design is compatible with OE master-cylinder output and ABS functions where those systems are used.
The front rotors measure 14.00 in. (355.60 mm) in diameter and 1.25 in. thick. They have a dual bolt pattern for 5 x 4.50 in. and 5 x 4.75 in. applications (5 x 114.30 mm and 5 x 120.65 mm). The included front calipers are red, forged billet aluminum, and use six pistons. BP-20 brake pads are included.
- Position: Front
- Minimum recommended wheel diameter: 17 in.
- Parking brake provision: No
- Quantity: Sold as a kit
This kit includes front rotors, front calipers, and brake pads. Rear rotors and rear calipers are not included. Front spindles, a master cylinder, brake booster, and brake hoses are also not included. The kit is not remanufactured.
Brand: Wilwood Disc Brakes. Manufacturer’s part number: 140-8922-R. Summit Racing part number: WIL-140-8922-R. UPC: 889545030235.
