Description
Bell & Gossett e-1510 1.5BC 15 HP 3-Phase ODP Pump – High-Efficiency End Suction Pump
The Bell & Gossett e-1510 1.5BC is a premium end-suction, base-mounted centrifugal pump engineered for commercial HVAC, industrial, and municipal applications. Featuring industry-leading efficiency, rugged cast-iron construction, and a 15 HP ODP (Open Drip Proof) motor, this pump delivers reliable performance and long service life while lowering operating costs.
Its e-Series hydraulic design ensures optimized flow, reduced NPSH requirements, and smoother operation, while the back pull-out configuration allows servicing without disturbing piping or motor alignment.
Key Features
-
High-Efficiency Design – Meets DOE efficiency standards, reducing operating costs.
-
Rugged Construction – Cast-iron casing with bronze impeller for superior durability.
-
Back Pull-Out Design – Service the pump without disturbing piping or motor alignment.
-
Versatile Motor Options – Supplied with a 15 HP, 3-phase, ODP motor for optimal ventilation.
-
Precision Machined – Ensures smooth, quiet operation with minimal vibration.
-
Long Service Life – Heavy-duty bearings and mechanical seals designed for demanding duty cycles.
Specifications
| Feature | Details |
|---|---|
| Model | e-1510 1.5BC |
| Pump Type | End suction, base-mounted centrifugal |
| Motor Power | 15 HP |
| Motor Type | ODP (Open Drip Proof) |
| Voltage | 230/460V |
| Phase | 3 |
| Impeller Material | Bronze |
| Casing Material | Cast iron |
| Mounting | Base-mounted |
| Seal Type | Mechanical |
| Applications | HVAC, industrial, municipal water |
| Serviceability | Back pull-out |
| Warranty | 1 Year (manufacturer) |
Comparison Table – Bell & Gossett e-1510 1.5BC vs. Armstrong 4300 vs. Taco FI Series
| Feature / Model | B&G e-1510 1.5BC | Armstrong 4300 | Taco FI Series |
|---|---|---|---|
| Pump Type | End suction | End suction | End suction |
| Motor Power | 15 HP | 15 HP | 15 HP |
| Motor Type | ODP | TEFC / ODP options | ODP |
| Casing Material | Cast iron | Cast iron | Cast iron |
| Impeller Material | Bronze | Bronze/Stainless | Bronze |
| Service Design | Back pull-out | Back pull-out | Back pull-out |
| Efficiency | DOE compliant | DOE compliant | Standard high-efficiency |
| Applications | HVAC, municipal, industrial | HVAC, chilled water, industrial | HVAC, water distribution |
| Best For | Balanced efficiency, serviceability | Energy savings, variable speed | Budget-friendly commercial duty |
FAQs – Bell & Gossett e-1510 1.5BC
Q1: What type of motor does the e-1510 1.5BC use?
It comes standard with a 15 HP, 3-phase, ODP motor for efficient cooling.
Q2: Can this pump be serviced without disturbing piping?
Yes, the back pull-out design allows pump servicing without disconnecting piping.
Q3: Is this pump DOE compliant?
Yes, it meets DOE efficiency standards, reducing energy costs.
Q4: What applications is it best suited for?
It’s ideal for commercial HVAC, industrial processes, and municipal water systems.
Q5: What is the impeller made of?
The impeller is precision-cast bronze for durability and corrosion resistance.
