Description
The Wilwood Forged Narrow Superlite 6R Big Brake Front Brake Kit (part number 140-15304-D) is an application-specific front brake upgrade featuring forged, six-piston radial-mount calipers and vented rotors. The design is described as compatible with OE master-cylinder output and ABS functions where used.
This kit includes a pair of 14.00-inch (355.60 mm) cross-drilled/slotted front rotors, each 1.25 inches thick, and black forged billet-aluminum front calipers. The rotors have a dual bolt pattern: 5 x 4.75 inches / 5 x 5.00 inches (5 x 120.65 mm / 5 x 127.00 mm).
- Six-piston front calipers and BP-10 brake pads included
- Minimum recommended wheel diameter: 18 inches
- Sold as a kit; front rotors, calipers and pads included
- No rear rotors or calipers, spindles, master cylinder, brake booster or brake hoses included
- No parking-brake provision
- Not remanufactured
Fitment requirement: Wilwood Forged Aluminum ProSpindles Drop Spindles are required for this brake kit to fit. Check the Required Parts tab and confirm application requirements before ordering.
